xConnect: Rapid Interaction Spoofing and Contact Identification

Cover Image for xConnect: Rapid Interaction Spoofing and Contact Identification

When you're testing contact sessions and contact identification, you don't want to wait for sessions to end on their own; it's too slow. We are going to set up a handful of bookmarkable API GET endpoints so you can rapidly start a session, identify as a specific contact, viw the current session data, and end the session so that the data is written to the database immediately instead of having to wait.

Endpoints for Ending Sessions and Viewing Session Data

VisitController.cs

_25
using Sitecore.Analytics;
_25
using Sitecore.Diagnostics;
_25
using System.Web.Mvc;
_25
_25
namespace Client.Foundation.xConnectPoc.Controllers
_25
{
_25
public class VisitController : Controller
_25
{
_25
[HttpGet]
_25
public JsonResult Data()
_25
{
_25
var currentTracker = Tracker.Current;
_25
var data = currentTracker.Interaction.ToVisitData();
_25
return Json(data, JsonRequestBehavior.AllowGet);
_25
}
_25
_25
[HttpGet]
_25
public JsonResult End()
_25
{
_25
Session.Abandon();
_25
Log.Info("Closing xDB session", this);
_25
return Json(new { Message = "xDB Session Closed" }, JsonRequestBehavior.AllowGet);
_25
}
_25
}
_25
}

InitializeRoutes.cs

_24
using System.Web.Mvc;
_24
using System.Web.Routing;
_24
using Sitecore.Pipelines;
_24
_24
namespace Client.Foundation.xConnectPoc.Pipelines.Initialize
_24
{
_24
public class InitializeRoutes : Sitecore.Mvc.Pipelines.Loader.InitializeRoutes
_24
{
_24
public override void Process(PipelineArgs args)
_24
{
_24
RouteTable.Routes.MapRoute(
_24
"VisitData", // Route name
_24
"api/visit/data",
_24
new { controller = "Visit", action = "Data" },
_24
new[] { "Client.Foundation.xConnectPoc.Controllers" });
_24
_24
RouteTable.Routes.MapRoute(
_24
"VisitEnd",
_24
"api/visit/end",
_24
new { controller = "Visit", action = "End" },
_24
new[] { "Client.Foundation.xConnectPoc.Controllers" });
_24
}
_24
}
_24
}

Patch.config

_10
<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/">
_10
<sitecore>
_10
<pipelines>
_10
<initialize>
_10
<!-- Only enable this in test environments -->
_10
<processor type="Client.Foundation.xConnectPoc.Pipelines.Initialize.InitializeRoutes, Client.Foundation.xConnectPoc" patch:before="processor[@type='Sitecore.Mvc.Pipelines.Loader.InitializeRoutes, Sitecore.Mvc']"/>
_10
</initialize>
_10
</pipelines>
_10
</sitecore>
_10
</configuration>

Now we need to set up the logic to get or set the contact and populate its fields. Getting or setting the contact also implies that we need to support contact identification. Modify the code below to suit your needs.

SpoofVisit.cs

_156
using Sitecore.Analytics;
_156
using Sitecore.Analytics.Model;
_156
using Sitecore.Analytics.Model.Entities;
_156
using Sitecore.Analytics.Pipelines.CreateVisits;
_156
using Sitecore.XConnect;
_156
using Sitecore.XConnect.Client;
_156
using Sitecore.XConnect.Collection.Model;
_156
using System.Linq;
_156
using System.Net;
_156
_156
namespace Client.Foundation.xConnectPoc.Pipelines.CreateVisit
_156
{
_156
public class SpoofVisit : CreateVisitProcessor
_156
{
_156
public override void Process(CreateVisitArgs args)
_156
{
_156
// We're using an email in the query string as the primary identification mechanism
_156
var email = args.Request.Params["email"];
_156
if (string.IsNullOrWhitespace(email))
_156
{
_156
return;
_156
}
_156
_156
var firstName = args.Request.Params["firstName"];
_156
var lastName = args.Request.Params["lastName"];
_156
_156
// IP address info, if you want
_156
if (!string.IsNullOrWhitespace(args.Request.Params["geoIp"]))
_156
{
_156
var geoip = args.Request.Params["geoIp"];
_156
var ipAddress = IPAddress.Parse(geoIp);
_156
args.Interaction.Ip = ipAddress.GetAddressBytes();
_156
}
_156
_156
args.Session.IdentifyAs("Email", email);
_156
_156
var manager = Sitecore.Configuration.Factory.CreateObject("tracking/contactManager", true) as Sitecore.Analytics.Tracking.ContactManager;
_156
if (manager == null)
_156
{
_156
return;
_156
}
_156
_156
if (Tracker.Current.Contact.IsNew)
_156
{
_156
// Save contact to xConnect; at this point, a contact has an anonymous
_156
// TRACKER IDENTIFIER, which follows a specific format. Do not use the contactId overload
_156
// and make sure you set the ContactSaveMode as demonstrated
_156
Tracker.Current.Contact.ContactSaveMode = ContactSaveMode.AlwaysSave;
_156
manager.SaveContactToCollectionDb(Tracker.Current.Contact);
_156
_156
// Now that the contact is saved, you can retrieve it using the tracker identifier
_156
var trackerIdentifier = new IdentifiedContactReference(Sitecore.Analytics.XConnect.DataAccess.Constants.IdentifierSource, Tracker.Current.Contact.ContactId.ToString("N"));
_156
_156
// Get contact from xConnect, update and save the facet
_156
using (XConnectClient client = Sitecore.XConnect.Client.Configuration.SitecoreXConnectClientConfiguration.GetClient())
_156
{
_156
try
_156
{
_156
var contact = client.Get(trackerIdentifier, new Sitecore.XConnect.ContactExpandOptions());
_156
_156
if (contact == null)
_156
{
_156
// Handle it
_156
}
_156
_156
client.SetFacet(contact, PersonalInformation.DefaultFacetKey, new PersonalInformation()
_156
{
_156
FirstName = firstName,
_156
LastName = lastName
_156
});
_156
_156
var emails = new EmailAddressList(new EmailAddress(email, true), "Home");
_156
client.SetFacet(contact, emails);
_156
_156
client.Submit();
_156
_156
// Remove contact data from shared session state - contact will be re-loaded
_156
// during subsequent request with updated facets
_156
manager.RemoveFromSession(Tracker.Current.Contact.ContactId);
_156
Tracker.Current.Session.Contact = manager.LoadContact(Tracker.Current.Contact.ContactId);
_156
}
_156
catch (XdbExecutionException ex)
_156
{
_156
// Manage conflicts / exceptions
_156
Sitecore.Diagnostics.Log.Error(ex.Message, ex, this);
_156
}
_156
}
_156
}
_156
else
_156
{
_156
var anyIdentifier = Tracker.Current.Contact.Identifiers.FirstOrDefault();
_156
_156
// Get contact from xConnect, update and save the facet
_156
using (XConnectClient client = Sitecore.XConnect.Client.Configuration.SitecoreXConnectClientConfiguration.GetClient())
_156
{
_156
try
_156
{
_156
var contact = client.Get(new IdentifiedContactReference(anyIdentifier.Source, anyIdentifier.Identifier), new ContactExpandOptions(PersonalInformation.DefaultFacetKey));
_156
_156
if (contact == null)
_156
{
_156
// Handle it
_156
}
_156
_156
if (contact.Personal() != null)
_156
{
_156
if (!string.IsNullOrEmpty(firstName))
_156
contact.Personal().FirstName = firstName;
_156
if (!string.IsNullOrEmpty(lastName))
_156
contact.Personal().LastName = lastName;
_156
_156
client.SetFacet(contact, PersonalInformation.DefaultFacetKey, contact.Personal());
_156
}
_156
else
_156
{
_156
client.SetFacet(contact, PersonalInformation.DefaultFacetKey, new PersonalInformation()
_156
{
_156
FirstName = firstName,
_156
LastName = lastName
_156
});
_156
}
_156
_156
var emailAddressList = contact.GetFacet<EmailAddressList>(EmailAddressList.DefaultFacetKey);
_156
if (emailAddressList != null)
_156
{
_156
// Change facet properties
_156
emailAddressList.PreferredEmail = new EmailAddress(email, true);
_156
emailAddressList.PreferredKey = "Home";
_156
_156
// Set the updated facet
_156
client.SetFacet(contact, EmailAddressList.DefaultFacetKey, emailAddressList);
_156
}
_156
else
_156
{
_156
// Facet is new
_156
var emails = new EmailAddressList(new EmailAddress(email, true), "Home");
_156
client.SetFacet(contact, EmailAddressList.DefaultFacetKey, emails);
_156
}
_156
_156
client.Submit();
_156
_156
// Remove contact data from shared session state - contact will be re-loaded
_156
// during subsequent request with updated facets
_156
manager.RemoveFromSession(Tracker.Current.Contact.ContactId);
_156
Tracker.Current.Session.Contact = manager.LoadContact(Tracker.Current.Contact.ContactId);
_156
}
_156
catch (XdbExecutionException ex)
_156
{
_156
// Manage conflicts / exceptions
_156
Sitecore.Diagnostics.Log.Error(ex.Message, ex, this);
_156
}
_156
}
_156
}
_156
}
_156
}
_156
}

Patch.config

_10
<configuration xmlns:patch="http://www.sitecore.net/xmlconfig/">
_10
<sitecore>
_10
<pipelines>
_10
<createVisit>
_10
<!-- Make sure to disable this in PROD -->
_10
<processor type="Client.Foundation.xConnectPoc.Pipelines.CreateVisit.SpoofVisit, Client.Foundation.xConnectPoc" patch:after="processor[@type='Sitecore.Analytics.Pipelines.CreateVisits.XForwardedFor, Sitecore.Analytics']" />
_10
</createVisit>
_10
</pipelines>
_10
</sitecore>
_10
</configuration>

I also found a browser extension for analytics testing that may be worth trying out.

Keep on building,

Marcel


More Stories

Cover Image for SPE Script Performance & Troubleshooting

SPE Script Performance & Troubleshooting

> Script never ends or runs too slow? Get in here.

Cover Image for Tips for Applying Cumulative Sitecore XM/XP Patches and Hotfixes

Tips for Applying Cumulative Sitecore XM/XP Patches and Hotfixes

> It's probably time to overhaul your processes

Cover Image for Troubleshooting 502 Responses in Azure App Services

Troubleshooting 502 Responses in Azure App Services

> App Services don't support all libraries

Cover Image for Azure PaaS Cache Optimization

Azure PaaS Cache Optimization

> App Services benefit greatly from proper configuration

Cover Image for NextJS: Short URL for Viewing Layout Service Response

NextJS: Short URL for Viewing Layout Service Response

> Because the default URL is 2long4me

Cover Image for Don't Ignore the HttpRequestValidationException

Don't Ignore the HttpRequestValidationException

> Doing so could be... potentially dangerous

Cover Image for JSS + TypeScript Sitecore Project Tips

JSS + TypeScript Sitecore Project Tips

> New tech, new challenges

Cover Image for Add TypeScript Type Checks to RouteData fields

Add TypeScript Type Checks to RouteData fields

> Inspired by error: Conversion of type may be a mistake because neither type sufficiently overlaps with the other.

Cover Image for Script: Boost SIF Certificate Expiry Days

Script: Boost SIF Certificate Expiry Days

> One simple script that definitely won't delete your system32 folder

Cover Image for JSS: Reducing Bloat in Multilist Field Serialization

JSS: Reducing Bloat in Multilist Field Serialization

> Because: performance, security, and error-avoidance

Cover Image for Year in Review: 2022

Year in Review: 2022

> Full steam ahead

Cover Image for On Mentorship and Community Contributions

On Mentorship and Community Contributions

> Reflections and what I learned as an MVP mentor

Cover Image for Content Editor Search Bar Not Working

Content Editor Search Bar Not Working

> Sometimes it works, sometimes not

Cover Image for Super Fast Project Builds with Visual Studio Publish

Super Fast Project Builds with Visual Studio Publish

> For when solution builds take too long

Cover Image for Security Series: App Service IP Restrictions

Security Series: App Service IP Restrictions

> How to manage IP rules "at scale" using the Azure CLI

Cover Image for Tips for Forms Implementations

Tips for Forms Implementations

> And other pro tips

Cover Image for NextJS: Unable to Verify the First Certificate

NextJS: Unable to Verify the First Certificate

> UNABLE_TO_VERIFY_LEAF_SIGNATURE

Cover Image for Critical Security Bulletin SC2024-001-619349 Announced

Critical Security Bulletin SC2024-001-619349 Announced

> And other scintillating commentary

Cover Image for How to Run Old Versions of Solr in a Docker Container

How to Run Old Versions of Solr in a Docker Container

> Please don't make me install another version of Solr on my local...

Cover Image for NextJS: Access has been blocked by CORS policy

NextJS: Access has been blocked by CORS policy

> CORS is almost as much of a nuisance as GDPR popups

Cover Image for Ideas For Docker up.ps1 Scripts

Ideas For Docker up.ps1 Scripts

> Because Docker can be brittle

Cover Image for On Sitecore Stack Exchange (SSE)

On Sitecore Stack Exchange (SSE)

> What I've learned, what I see, what I want to see

Cover Image for Hello World

Hello World

> Welcome to the show

Cover Image for On Sitecore Development

On Sitecore Development

> Broadly speaking

Cover Image for Tips for New Sitecore Developers

Tips for New Sitecore Developers

> If I had more time, I would have written a shorter letter

Cover Image for Sitecore Symposium 2022

Sitecore Symposium 2022

> What I'm Watching 👀

Cover Image for NextJS/JSS Edit Frames Before JSS v21.1.0

NextJS/JSS Edit Frames Before JSS v21.1.0

> It is possible. We have the technology.

Cover Image for Early Returns in React Components

Early Returns in React Components

> When and how should you return early in a React component?

Cover Image for Symposium 2022 Reflections

Symposium 2022 Reflections

> Sitecore is making big changes
